Features
Sentinel™ Gold Microprocessor Control system
- Has audible and visual alarms
- Displays all safety information on one screen
- Centered and angled down for easy reach & viewing
- Selectable Quickstart mode for fast operation
Dual DC-ECM Blower System
- Energy-efficient with 70% energy savings compared to AC motor
- Stable airflow, despite building voltage fluctuations & filter loading
ULPA Filter
- 10 x filtration efficiency compared to HEPA filter
- 99.999% at 0.1 to 0.3 micron, ULPA as per IEST-RP-CC001.3 USA or >99.999% at MPPS, H14 as per EN 1822 EU
Cabinet construction
- Tempered Glass Side walls – increases visibility and prevents the operator from experiencing a “boxed-in” feeling
- Multi-piece work tray, autoclavable
Ergonomic features
- Motorized window – Aerosol tight window seal that automatically stops at safe operating height
- LED Lamps – energy efficient and lasts longer than fluorescent
Isocide™ Antimicrobial Powder Coating
- Eliminates 99.9% of surface bacteria within 24 hours of exposure
Models
| Item Code | Model Code | Description |
|---|---|---|
| 220-240 VAC, 50/60 Hz | ||
| 2011036 | AC2-3E8-TU | Airstream® Plus Class II, Biological Safety Cabinet (E-Series) TU, 3ft/0.9m |
| 2011005 | AC2-4E8-TU | Airstream® Plus Class II, Biological Safety Cabinet (E-Series) TU, 4ft/1.2m |
| 2010981 | AC2-5E8-TU | Airstream® Plus Class II, Biological Safety Cabinet (E-Series) TU, 5ft/1.5m |
| 2011007 | AC2-6E8-TU | Airstream® Plus Class II, Biological Safety Cabinet (E-Series) TU, 6ft/1.8m |
Accessories
| Item Code | Model Code | Description |
|---|---|---|
| 5170251 | UV-15A | UV Lamp for 2ft, 3ft Cabinets and AC3-4B |
| 5170255 | UV-30A | UV Lamp for 4ft, 5ft, 6ft Cabinets except AC3-4B |
| Service Fixtures | ||
| 5170410 | SF-1G20 | European Style Service Fixture with 20mm Thread Length – Gas |
| 5170457 | SF-1V20 | European Style Service Fixture with 20mm Thread Length – Vacuum |
| 5170503 | SF-1N20 | European Style Service Fixture with 20mm Thread Length – Nitrogen |
| 5170502 | SF-1A20 | European Style Service Fixture with 20mm Thread Length – Air |
| 5170458 | SF-1W20 | European Style Service Fixture with 20mm Thread Length – Water |
| 5170504 | SF-2U22 | American Style Service Fixture with 22mm Thread Length – Universal |
| 5170026 | CU-Pipe | Copper Piping for Service Fixture – Must be Factory Installed |
| Support Stands | ||
| SPC-_A0 Gen2 | Support Stand with Caster Wheels (Height 28”) | |
| SPC-_B0 Gen 2 | Support Stand with Caster Wheels (Height 34”) | |
| SAL-_A0 Gen 2 | Support Stand with Leveling Feet – I (Height 28”) | |
| SAL-_B0 Gen 2 | Support Stand with Leveling Feet – I (Height 34”) | |
| IV Bars | ||
| 5170499 | IV-910 | IV Bar 910mm |
| 5170231 | IV-1215 | IV Bar 1215mm |
| 5170500 | IV-1520 | IV Bar 1520mm |
| 5170501 | IV-1825 | IV Bar 1825mm |
| Pre-Filters | ||
| 5090061 | PF-41 | Prefilter, 895x125x6mm, AC2-3ft |
| 5090062 | PF-42 | Prefilter, 1200x125x6mm, AC2-4ft |
| 5090063 | PF-43 | Prefilter, 1505x125x6mm, AC2-5ft |
| 5090064 | PF-44 | Prefilter, 1810x125x6mm, AC2-6ft |
| VHP Ports | ||
| 5170552 | VHP-IN PORT | VHP Port (In) |
| VHP Out Port (for cabinet with exhaust collar installed) | ||
| 5170684 | VHP-ECO/OUT 3ft | VHP Port (Out) 3ft |
| 5170615 | VHP-ECO/OUT 4ft | VHP Port (Out) 4ft |
| 5170616 | VHP-ECO/OUT 5ft | VHP Port (Out) 5ft |
| 5170617 | VHP-ECO/OUT 6ft | VHP Port (Out) 6ft |
| VHP Out Top Box (for cabinet without exhaust collar installed) | ||
| 5170685 | VHP-OUT TOP BOX 3ft | VHP Top Box (Out) 3ft |
| 5170612 | VHP-OUT TOP BOX 4ft | VHP Top Box (Out) 4ft |
| 5170613 | VHP-OUT TOP BOX 5ft | VHP Top Box (Out) 5ft |
| 5170614 | VHP-OUT TOP BOX 6ft | VHP Top Box (Out) 6ft |
