Sigma 1-7

Category: Brand:

The Sigma 1‑7 is designed for the separation of blood and urine specimens in medical practices and small labs, and due to its strong performance it is also used in environmental analytics, schools and universities.

The Sigma 1‑7 compact benchtop centrifuge is especially good in delivering exact results in a very short time. With these attributes combined with convenient, intuitive operation and the motorised lid lock, which enables effortless closing of the centrifuge, it offers more than comparable devices in its segment.

What makes the Sigma 1‑7 benchtop centrifuge so attractive
The Sigma 1‑7 benchtop centrifuge is the only one in its segment that supports up to ten saved programs. This allows routine protocols to be stored and work processes to be optimised. In operation this small centrifuge runs with especially low vibration, quietly and pleasantly.

The perfectly matched fixed-angle rotor of the Sigma 1‑7, with a maximum capacity of 6 x 15 ml, is well suited to meet the demands of small volumes of specimens. The maximum RCF of 6,153 x g and the short braking and acceleration times of this small centrifuge allow separation times to be shortened considerably.

Fixed-angle rotor

max. volume90 ml
max. speed8,000 rpm
max. RCF6,153 x g


Product options

  • Centrifuge & rotor package

User

  • Doctors in private practice
  • Veterinary practices
  • Small laboratory workstations
  • Hospitals

Technical specifications

Max. capacity [ml]
fixed-angle rotor6 x 15
Max. RCF6.153
Max. speed [rpm]8.000
Min. speed [rpm]200
Noise level at maximum speed (approximate) [dB(A)]
fixed-angle rotor 91429≤ 58
Max. acceleration time [s]
fixed-angle rotor 91429≤ 13
Max. braking time [s]
fixed-angle rotor 91429≤ 11
Temperature setting range [°C]
Power consumption [W]55
Height x Width x Depth [mm]271 x 310 x 418
Height with open lid [mm]527
Weight without rotor [kg]13
